- SearchE-709 Compact and Cost-Optimized Digital Piezo ControllerProduct Description Specifications Downloads Quote / Order
Fast digital servo controller
Benchtop (.xRG) or OEM board (.xR). Voltage range -30 to 130 V.
USB, digital RS-232, fast serial interface with up to 25 MBit/s. Additional high-bandwidth analog control input / sensor input. Analog output, e.g., for external amplifiers.
User software and functions
PIMikroMove, PI General Command Set (GCS). Drivers for NI LabVIEW, shared libraries for Windows and Linux. Compatible with µManager, MetaMorph, MATLAB. Wave generator. Linearization. Data recorder. Autozero. Trigger I/O. Software-configurable parameters.
Fields of application
- Multiphoton microscopy, confocal microscopy
- 3-D imaging
- Autofocus systems
- Surface analysis
- Wafer inspection
Short Instructions PZ289Digital Piezo Controllers E-709.xxG / E-727 / E-7541.0.0 2019/091.0.0 2019/09Documentation
Technical Note A000T0074Guide to Grounding and Shielding2018-11-222018-11-22Documentation
User Manual PZ222E-709 Digital Piezo Controller, 1 Channel, -30 to 130 V1.2.0 2019-01-31EnglishDocumentation
Technical Note E709T0002SPI Interface Description2011-02-08English
General Software DocumentationGeneral Software Documentation
Software Manual PZ225GCS LabVIEW Driver Set for E-709 Digital Piezo Controller6.3.1 2013-12-09EnglishGeneral Software Documentation
Technical Note A000T0028PI Update Finder: Description and general instructionEnglishGeneral Software Documentation
Technical Note A000T0032PI Update Finder: Updating software without internet connectionEnglishGeneral Software Documentation
Software Manual SM146GCS Array Data Format1.2.1EnglishGeneral Software Documentation
Software Manual SM148PIMikroMove2.13.0 2019-04-18EnglishGeneral Software Documentation
Software Manual SM151EPI GCS2 DLL2.10.0 2019-08-26EnglishGeneral Software Documentation
Software Manual SM154Merge Tool for use with Driver Sets for NI LabVIEW Software6.18.0 2018-10-16EnglishGeneral Software Documentation
Software Manual SM155PI MATLAB Driver GCS 2.01.1.0 2016-02-291.1.0 2016-02-29General Software Documentation
Software Manual PZ181GCS Driver Set for use with NI LabVIEW Software, for Controllers with Analog Inputs6.3.1English
