P-15x.xxH PICA Shear Actuators

Compact Multi-Axis Actuators with Inner Hole

  • Single and multi-axis versions
  • Travel ranges to 10 × 10 × 10 µm
  • Extreme reliability: >109 cycles
  • Picometer resolution
  • Short lead times
P-15x.xxH PICA Shear Actuators
Product Description Specifications Downloads Quote / Order

Piezo shear actuators with inner hole

Operating voltage -250 to 250 V. Lateral displacement is based on the piezoelectric shear effect. Excellent dynamics with minimum electric power requirement.

Variants without inner hole or for use in cryogenic and UHV environments to 10-9 hPa.

Possible modifications

  • Piezo ceramic material
  • Nonmagnetic versions
  • Operating voltage range, displacement, layer thickness, cross-sectional dimension
  • Load capacity, force generation
  • Mechanical interfaces: flat, spherical, metal, ceramic, glass, sapphire, etc.
  • Extra-tight length tolerances

Fields of application

  • Industry and research
  • Low temperature / vacuum versions to 10-9 hPa
  • Scanning applications
  • Microscopy
  • Precision mechanics
  • Switching applications



Specifications

Datasheet

Datasheet P-15x.xxH

Version / Date
2018-04-25
pdf - 917 KB
Version / Date
2018-04-25
pdf - 920 KB
Version / Date
2018-05-14
pdf - 721 KB
